TP15G/TP18G High Pressure Screw Compressor
Product Details:
- Size Standard
- Product Type High Pressure Screw Compressor
- Usage Industrial
- Configuration Stationary
- Power Source Ac Power
- Silent Yes
- Voltage 220-240 Volt (v)
- Click to View more
X
TP15G/TP18G High Pressure Screw Compressor Price And Quantity
- 1 Piece
TP15G/TP18G High Pressure Screw Compressor Product Specifications
- Yes
- Standard
- Industrial
- Ac Power
- High Pressure Screw Compressor
- Yes
- Stationary
- 220-240 Volt (v)
TP15G/TP18G High Pressure Screw Compressor Trade Information
- 1000 Piece Per Month
- 30 Days
Product Description
As a reputed entity of this industry, we offer a wide assortment of High Pressure Screw Compressor in the market. Known for easy shifting, our offered compressor is used for removal of debris and unwanted small materials from industry surroundings. This High Pressure Screw Compressor is widely used to convert power into potential energy stored in pressurized air. Reliable to use, great functionality, robust design and heat resistance are features of offered screw compressor. The excellent volumetric efficiency and brilliant technology of the product makes it a highly popular choice.
Technical Specifications
| Model | Maximum work pressure | FAD | Air supply temperature | Power | Noise | Oil content | Weight | Cooling fan power | Compressed Air Outlet Diameter | Dimension | |
| LWH | |||||||||||
| Mpa | m3/min | oC | kW | HP | dB(A) | PPM | Kg | kW |
| mm | |
| TP15G | 3.0 | 1.45 | +25oC | 15 | 20 | 63 | 2 | 848 | 0.64 | 3/4 | 160011501315 |
| 4.0 | 1.12 | ||||||||||
| TP18G | 3.0 | 1.73 | 18.5 | 25 | 65 | 868 | |||||
| 4.0 | 1.38 | ||||||||||
| TP22G | 3.0 | 2.35 | 22 | 30 | 65 | 900 | |||||
| 4.0 | 1.65 | ||||||||||
| TP30G | 3.0 | 2.93 | 30 | 40 | 66 | 1217 | 2 | 3/4 | 190014201460 | ||
| 4.0 | 2.28 | ||||||||||
| TP37G | 3.0 | 3.65 | 37 | 50 | 67 | 1232 | |||||
| 4.0 | 2.83 | ||||||||||
| TP45G | 3.0 | 4.7 | 45 | 60 | 68 | 1286 | |||||
| 4.0 | 3.57 | ||||||||||
| TP55G | 3.0 | 6 | 55 | 75 | 70 | 2000 | 1 | 205014601500 | |||
| 4.0 | 4.5 | ||||||||||
| TP75G | 3.0 | 7.9 | 75 | 100 | 73 | 3820 | 4.3 | 1 | 225016001800 | ||
| 4.0 | 6.5 | ||||||||||
| TP90G | 3.0 | 10 | 90 | 125 | 73 | 3900 | |||||
| 4.0 | 7.84 | ||||||||||
| TP110G | 3.0 | 12.2 | 110 | 150 | 78 | 3920 | |||||
| 4.0 | 9.7 | ||||||||||
| TP132G | 3.0 | 14.2 | 132 | 175 | 78 | 4080 | 7 | 1 1/2 | 240017001550 | ||
| 4.0 | 11.68 | ||||||||||
| TP160G | 3.0 | 17.3 | 160 | 215 | 78 | 6450 | 266018001800 | ||||
| 4.0 | 14.2 | ||||||||||
| CM185G | 3.0 | 19.6 | 185 | 250 | 78 | 6520 | |||||
| 4.0 | 16.6 | ||||||||||
| TP200G | 3.0 | 22.8 | 200 | 270 | 78 | 6560 | |||||
| 4.0 | 17.9 | ||||||||||
| TP250G | 3.0 | 28.2 | 250 | 340 | 78 | 7200 | 11 | 2 |
| ||
